Home /Products/Oil Free Air Compressors/2HP 50L 8Bar 220V Oil Free Silent Piston Air Compressor For Dental Clinic

2HP 50L 8Bar 220V Oil Free Silent Piston Air Compressor For Dental Clinic

1
MOQ
Negotiation
Price
2HP 50L 8Bar 220V Oil Free Silent Piston Air Compressor For Dental Clinic
Features Gallery Product Description Chat Now
Features
Specifications
Power: 1680w
Tank: 50L
Speed: 1400rpm
Voltage: 220v
Pressure: 8bar
Air Flow: 145L/min
Size: 41*41*94cm
Weight: 45kg
Highlight:

50l silent air compressor

,

dental 2hp oil free air compressor

,

8Bar oil free air compressor 2hp
Basic Infomation
Place of Origin: CHINA
Brand Name: DONGJIA
Certification: CE
Model Number: YX60C-1680-50L
Payment & Shipping Terms
Packaging Details: carton box
Delivery Time: 5-8working days
Payment Terms: T/T
Supply Ability: 500pcs per day
Product Description

2HP 50L 8Bar 220V Oil-Free Silent Piston Air Compressor for Dental Clinic

50L Vertical Tank 1680W 8 bar 145 L/min
YX60-1680-50L Oil Free Air Compressor

High-capacity, whisper-quiet, 100% oil-free compressed air for dental clinics, laboratories, workshops, and OEM brands that demand clean power without the maintenance.

View Full Specifications Common Questions
2HP 50L 8Bar 220V Oil Free Silent Piston Air Compressor For Dental Clinic
Product Introduction
Clean, quiet, high-output compressed air for professionals who cannot compromise on air quality.

The YX60-1680-50L oil free air compressor is built for users who need serious airflow without oil contamination, daily maintenance, or excessive noise. With a 50L vertical tank and a 1680W oil-free motor, it delivers a rated displacement of 145 L/min at 8 bar — enough reserve pressure and flow to power dental handpieces, laboratory instruments, spray guns, small pneumatic tools, and brand-label OEM equipment.

Unlike traditional lubricated compressors, this unit produces 100% oil-free air, eliminating the risk of oil aerosol entering sensitive workspaces. Its vertical tank design keeps the footprint small while giving you the capacity of a larger workshop unit, making it ideal for clinics, labs, and compact workshops where floor space matters. A full 5-fold protection system, Class F insulation, and intelligent thermal management keep the failure rate below 0.02%, even in ambient temperatures from -30℃ to 40℃.

Features & Characteristics
Engineered reliability for demanding environments — from hot workshops to cold laboratories.
⚡
175V Low-Voltage Startup

Reliable motor start even when incoming voltage is low or unstable. Critical for clinics, rural labs, and older buildings with weak power supply.

🌡️
Extreme Temperature Range (-30℃ to 40℃)

Tested and proven across diverse climates. Cold-rolled steel motor and Class F enameled wire resist heat and cold extremes.

🛡️
Ultra-Low Failure Rate (<0.02%)

Five-fold motor protection drastically reduces burnout risk and extends service life, lowering downtime and warranty costs.

🔥
Optimized Thermal Management

Cold-rolled steel motor for slower temperature rise; premium aluminum housing for faster heat dissipation; Class F enameled wire with higher melting-point insulation; built-in thermal protector for automatic overload protection.

⚙️
Seamless Cylinder Sleeve

Minimized friction delivers smoother piston travel, higher efficiency, lower noise, and longer wear resistance.

🛢️
Truly Oil-Free Operation

No lubricating oil in the compression chamber means zero oil contamination, no disposal of waste oil, and no routine oil changes.

Why Choose Us
Purpose-built solutions for the buyers who matter most to your business.
Dental Clinics

Clean, oil-free air protects handpieces, air syringes, and patient safety. Quiet operation keeps treatment rooms calm.

Laboratories

Stable 8 bar output and oil-free air protect analytical instruments, glassware, and controlled experiments from contamination.

Wholesalers & Trading Companies

Competitive vertical-tank design with universal 220V voltage and CE-ready construction simplifies global distribution.

Brand Owners & OEMs

Low failure rate and modular construction make private-label and warranty programs more profitable and easier to support.

Home Improvement & Workshop

The 50L vertical tank stores enough air for staplers, brad nailers, inflators, and light spray work without taking up floor space.

Lower Total Cost of Ownership

No oil to buy, no oil changes, no oily condensate disposal. The 1680W motor and large tank reduce cycle frequency and energy waste.

Technical Specifications
YX60-1680-50L detailed parameters.
Model No. YX60-1680-50L
Product Type Oil free air compressor
Rated Pressure 8 bar / 116 psi
Displacement 145 L/min
Motor Speed 1400 R.P.M
Voltage 220V / 50Hz
Tank Capacity 50L vertical tank
Rated Power 1680W
Dimensions 41 × 41 × 94 cm
Net Weight 45 kg
Low-Voltage Startup 175V supported
Operating Temperature -30℃ to 40℃
Insulation Class Class F enameled wire
Protection 5-fold motor protection + built-in thermal protector
Applications Dental, laboratory, workshop, painting, inflation, OEM
Values are for reference; final specifications may vary by regional configuration. Custom voltage, plug, color, and private-label branding are available on request.
Frequently Asked Questions
Quick answers for buyers and distributors.
Is this compressor really oil-free?

Yes. The YX60-1680-50L uses an oil-free piston design. There is no oil lubrication in the compression chamber, so the output air contains zero oil contamination — ideal for dental, laboratory, and food-safe environments.

What can a 1680W / 50L oil free air compressor run?

It easily powers dental handpieces, lab air tools, brad nailers, staplers, tire inflators, airbrushes, and small spray guns. The 50L vertical tank gives you longer continuous operation before the motor cycles.

Does it work in cold climates or low-voltage buildings?

Yes. The 175V low-voltage startup ensures reliable starting under weak power, and the unit is rated for operation from -30℃ to 40℃ with cold-rolled steel motor and Class F insulation.

How loud is it?

The seamless cylinder sleeve and optimized thermal design keep mechanical noise and vibration to a minimum. It is suitable for indoor clinics, labs, and residential workshops.

Do you support OEM / private label?

Yes. We support custom branding, color, voltage, plug type, packaging, and user manuals. Contact us with your target market and order quantity.

What maintenance does the 50L vertical tank compressor need?

Routine maintenance is minimal: drain the tank condensate periodically, keep air filters clean, and inspect hose connections. Because it is oil-free, there are no oil changes or oil disposal steps
