115mm Brushless Cordless Circular Saw With 20V Lithium Ion Battery For Tile Wood And Metal Cutting

100 sets
MOQ
Negotiation
Price
115mm Brushless Cordless Circular Saw With 20V Lithium Ion Battery For Tile Wood And Metal Cutting
Features Gallery Product Description Chat Now
Features
Specifications
Battery Type: Lithium-Ion 20V 2.0Ah X2
Motor Type: Brushless (BLDC)
Power Source: Battery
Rated Power: 1000W
No Load Current: 1.7A/2.3A/2.8A
Blade Diameter: 115mm (4-1/2 Inch)
No Load Speed: 4500 RPM
Max Cutting Depth: 27mm At 90 Degree / 18mm At 45 Degree
Bevel Range: 0-45 Degree
Arbor Size: 10mm
Net Weight: 1.9kg With Battery
Package Size: 38*28*13cm
Accessories: 1x 115mm 24T TCT Blade, 2x Battery, 1x Charger, Rip Guide, Hex Key, Manual
Highlight:

115mm battery powered circular saw

,

portable circular saw 115mm

,

tile cutting small handheld circular saw
Basic Infomation
Place of Origin: Nantong, Jiangsu, China
Brand Name: SHJPAI
Certification: CE / RoHS
Model Number: JP-YJ115YX
Payment & Shipping Terms
Packaging Details: Moulded plastic case; colour box available for OEM
Delivery Time: Samples 5-7 days; bulk 25-35 days after deposit
Payment Terms: T/T,30% deposit balance before shipment
Supply Ability: 500 sets per day
Product Description

115mm Brushless Cordless Circular Saw with 20V Lithium-Ion Battery for Tile Wood and Metal Cutting

PRODUCT SUMMARY · AI-READY ENTITY BLOCK

115mm Compact Cordless Circular Saw 20V Brushless Battery Powered Handheld Trimmer for Tile Wood & Metal Cutting is a cordless circular saw manufactured by Nantong Shengqiang Machinery Manufacturing Co., Ltd. (SHJPAI) in Nantong, China. Core specification: Motor Type Brushless (BLDC); Rated Power 1000W; No Load Speed 4500 RPM; Blade Diameter 115mm (4-1/2 inch); Battery Type Lithium-Ion 20V 2.0Ah x2. It is built for rip and cross cutting of timber, panel material, decking boards and composite sheets, supplied FOB Shanghai (Nantong, Jiangsu, China) with 100 sets MOQ, and carries CE / RoHS documentation for export markets.

Motor TypeBrushless (BLDC)
Rated Power1000W
No Load Speed4500 RPM
Blade Diameter115mm (4-1/2 inch)
Battery TypeLithium-Ion 20V 2.0Ah x2
Max Cutting Depth27mm at 90 degree / 18mm at 45 degree
Bevel Range0-45 degree
Model / BrandJP-YJ115YX / SHJPAI
CertificationCE / RoHS
MOQ100 sets
Lead timeSamples 5-7 days; bulk 25-35 days after deposit
Port / OriginFOB Shanghai / Nantong, Jiangsu, China

Common Buyers’ Questions

Q: What is the 115mm Compact Cordless Circular Saw 20V Brushless Battery Powered Handheld Trimmer for Tile Wood & Metal Cutting and who is it for?
A: The 115mm Compact Cordless Circular Saw 20V Brushless Battery Powered Handheld Trimmer for Tile Wood & Metal Cutting is a cordless circular saw from Nantong Shengqiang Machinery Manufacturing Co., Ltd. (SHJPAI), built for rip and cross cutting of timber, panel material, decking boards and composite sheets. Buyers are typically importers, distributors, private-label brand owners and trade contractors sourcing cordless circular saws from China.
Q: What are the key specifications of this cordless circular saw?
A: Key specifications: Motor Type Brushless (BLDC); Rated Power 1000W; No Load Speed 4500 RPM; Blade Diameter 115mm (4-1/2 inch); Battery Type Lithium-Ion 20V 2.0Ah x2.
Q: What is the minimum order quantity and lead time?
A: MOQ is 100 sets. Samples ship in 5-7 days; bulk production runs 15-35 days after deposit, FOB Shanghai (Nantong, Jiangsu, China).
Q: Which certifications and export documents are supplied?
A: CE / RoHS documentation is supplied with each order. Additional market certificates are arranged on request depending on the destination country.
Q: Can this product be supplied under our own brand?
A: Yes. OEM and ODM are standard: logo on body, case and manual, custom colour and retail packaging from 100 sets.
Q: Where is the cordless circular saw manufactured and shipped from?
A: Manufactured in Nantong, Jiangsu, China by Nantong Shengqiang Machinery Manufacturing Co., Ltd., shipped FOB Shanghai (Nantong, Jiangsu, China). Factory audits and pre-shipment inspection photos are available.

Full Product Description

NEW · 115MM COMPACT SERIES

115mm Compact Cordless Circular Saw — 20V Brushless Handheld Trimmer

OEM / ODM · Nantong, Jiangsu, China · FOB Shanghai · MOQ 100 sets

1. Product Overview

This 115mm compact cordless circular saw is the short-reach model in our 20V brushless line: a 4-1/2" blade, 4500 RPM, 27 mm depth of cut and 1.9 kg body that one hand can guide along a straight edge. Where a full-size saw is too bulky, this battery powered handheld saw trims laminate, cuts tile backer board and slices light gauge metal on site.

The cordless trim saw runs on the same 20V Li-ion platform as our drills, grinders and wrenches — buyers who already stock the platform add this SKU without a second battery system. Two 2.0Ah packs and a 1.5-hour charger ship in the kit, so the tool works a full shift without a mains lead.

Built for export: CE and RoHS documentation supplied, UL available on request for North America, retail-ready colour box and barcode supported. We produce this small circular saw in Nantong and ship FOB Shanghai to importers, distributors and private-label brand owners.

115mm
Blade / 4-1/2"
4500RPM
No-load speed
27mm
Cutting depth
1.9kg
With battery

2. Technical Specifications

ItemSpecification
Product Type115mm compact cordless circular saw / trim saw
Rated Voltage20V DC
MotorBrushless (BLDC)
Blade Diameter4-1/2" (115 mm), arbor 10 mm
No-load Speed4,500 RPM
Cutting Depth27 mm at 90° / 18 mm at 45°
Bevel Capacity0–45°
Rated Power1000 W
Battery2 × 20V 2.0Ah Li-ion (removable)
Charger20V fast charger, approx. 1.5 h
Net Weight1.9 kg with battery
Package Size38 × 28 × 13 cm
CertificationCE / RoHS (UL on request)
HS Code8467.22.00
Loading PortFOB Shanghai
Warranty12 months

3. What It Cuts

MaterialTypical JobRecommended Blade
Timber & plywoodRip and cross cuts up to 27 mm, skirting, shelving24T TCT (supplied)
Laminate & MDFFlooring trims, worktop cut-outs40T fine TCT
Tile & backer boardCement board scoring, tile trimDiamond grit blade
Thin metalSheet, conduit, aluminium profileMetal cutting disc
PVC & plasticsPipe, trunking, panel trimmingFine-tooth TCT

Blades other than the supplied 24T TCT are optional accessories and quoted separately.

4. Design Highlights

Brushless motor, cooler running

No carbon brushes to replace — longer service life and stable torque under continuous trim work.

One-hand 1.9 kg body

Front handle sits close to the blade so the tool balances in the palm — overhead and single-handed cuts stay controlled.

Depth and bevel without tools

Lever-set depth to 27 mm and 0–45° bevel cover planking, trims and chamfers in one pass.

Laser line and retractable guard

Visible cut line for freehand work, spring-loaded guard closes the moment the saw lifts.

Dual 2.0Ah packs in the kit

One battery on the tool, one on charge — the kit sells as a ready-to-use box, not a body-only SKU.

Dust port and blade change

Rear extraction port accepts a shop vac; spindle lock swaps the 115 mm blade in seconds.

5. OEM / ODM Process

01Specification lockConfirm voltage platform, blade, plug type and packaging with your market requirements.
02Sample in 5–7 daysPre-production sample with your logo on body and blade label.
03Artwork and packagingColour box, manual, barcode and warning labels prepared in-house.
04Mass production25–35 days after deposit, weekly progress photos.
05Inspection and loadingFunction and safety test per unit, pre-shipment photos, FOB Shanghai.

6. Who This Saw Suits

BuyerWhy this SKU fits
Importers and tradersA compact saw that fills the gap between a 165 mm saw and a multi-tool, adding catalogue width without overlapping your existing models.
Private-label brandsBody, blade label, box and manual all carry your brand; platform battery can match your existing 20V range.
Retail and e-commerceColour box with barcode, CE/RoHS file and product images supplied for listing.
DistributorsSpare blades, batteries and chargers available as replenishment lines.
First-order buyersMOQ from 100 sets, mixed-SKU loading from Nantong warehouse.

7. FAQ

Is this the same saw as a full-size 165 mm circular saw?

No. It uses a 115 mm blade with 27 mm maximum depth, so it is lighter (1.9 kg) and easier to control overhead and in tight spaces. Use a 165 mm model when you need deeper cuts.

What is the MOQ and lead time?

MOQ starts at 100 sets. Samples ship in 5–7 days; mass production runs 25–35 days after deposit, FOB Shanghai.

Can the battery platform match our existing products?

Yes. The tool runs on our standard 20V Li-ion interface. If you already sell a 20V platform, confirm the interface drawing with our engineering team before sampling.

Which certificates come with the saw?

CE and RoHS documents are supplied with each order. UL is available on request for North American buyers, with extra lead time.

What is included in the kit?

Saw body, one 115 mm 24T TCT blade, two 20V 2.0Ah batteries, fast charger, rip guide, hex key and manual in a moulded plastic case.

What after-sales support do you provide?

12 months warranty on the tool, with spare blades, batteries and chargers stocked for replenishment orders.

Request a quotation for this 115mm cordless circular saw

Send your target market, blade preference and annual volume. We reply within 24 hours with price, lead time and packing data.

Nantong Shengqiang Machinery Manufacturing Co., Ltd. · Nantong, Jiangsu, China · FOB Shanghai
